This 50MHz Crystal Oscillator is a high-precision, compact timing solution engineered for demanding electronic applications. Housed in a small 5.0 x 3.2mm package and operating from a 3.3V supply, it delivers exceptional frequency stability and accuracy for reliable system performance.

Key Features

• High Precision Frequency: Stable 50MHz output signal for precise system timing and synchronization.

• Exceptional Accuracy: ±1ppm initial frequency tolerance ensures minimal deviation at the point of manufacture.

• Superior Temperature Stability: Maintains consistent performance across a wide industrial temperature range of -40°C to +85°C.

• Compact Form Factor: The small 5.0 x 3.2mm footprint saves valuable board space, ideal for miniaturized designs.

• Single Supply Voltage: Designed for easy integration into modern 3.3V digital systems.

Applications

This oscillator is ideally suited for applications where timing integrity is paramount, including:

• Telecommunications Equipment: Network switches, routers, and base stations.

• Data Center & Networking: High-speed servers, network interface cards, and timing cards.

• Industrial Electronics: Programmable Logic Controllers (PLCs), industrial automation, and measurement systems.

• Test & Measurement Equipment: Requiring a highly accurate and stable timebase.

• Consumer Electronics: High-end audio/video equipment and gaming consoles.

Specification

Dimension
