10MHz 3V SMD5032 VCTCXO

Frequency: 10MHz
Voltage: 3V
Waveform: Clipped Sine Wave
Initial Accuracy (Reference Temperature): ±1ppm
Operating Temperature Range: -30~75℃

This 3V VCTCXO (Voltage Controlled Temperature Compensated Crystal Oscillator) delivers a stable 10MHz clipped sine wave output. It features excellent initial accuracy of ±1ppm and reliable operation across a wide -30°C to +75°C temperature range, making it ideal for precision timing and communication systems.

Specification

	Parameter	Value			Unit	Test Condition
	Parameter	Min.	Type	Max.	Unit	Test Condition
Power consumption	Supply Voltage		3.0		VDC
Power consumption	Current Consumption			3.0	mA
Output	Nominal Frequency	10.000			MHz
	Waveform	Clipped Sine wave			—--
	Load	10KΩ//10pF
Frequency Stability	Initial Accuracy (Reference Temperature)	-1		+1	ppm	25℃
	Temperature characteristics	-5		+5	ppm	@25℃
	Power Characteristics	-0.2		+0.2	ppm	Vcc±5%
	Phase Noise			-130	dBc/Hz	@1KHz
	Voltage-Controlled Voltage Input (VC)	0.5	1.5	2.5	V
	Frequency Adjustment Range	±4		±10	ppm
	Reference Voltage Output (Vref)	0.8	-	-	V
Ambient Temperature	Operating Temperature Range	-30		75	℃
Ambient Temperature	Storage Temperature Range	-40		105	℃
