Min.

Type

Max.

Power consumption

Power Supply

Rated Voltage

14.25

15.0

15.75

VDC

Vcc±5%

Limiting Voltage

11.75

15.75

VDC

Current

Start-up Current

270

mA

@Vcc±5%,25℃

Operating Current

100

mA

@Vcc±5%,25℃

Output

Nominal Frequency

10.000

MHz

Waveform

Sine wave

—--

Output Power

7.0

dBm

Load: 50Ω

Harmonic

-30

dBc

Load: 50Ω

Spurious

-70

dBc

Load: 50Ω

Load

47.5

50

52.5

Ω

Load ± 5%

Frequency Stability

Initial Accuracy (Factory Calibration)

-0.1

+0.1

ppm

VC=2.0V, 25℃, power on for 30 minutes

Aging

Daily

-1.0

+1.0

ppb

Tested after 30 days of continuous power-on

Yearly

-0.2

+0.2

ppm

In the first year, the test was conducted after 30 consecutive days of power-on.

Five Years

-0.5

+0.5

ppm

Temperature characteristics

-0.1

±0.05

+0.1

ppm

-40～85℃ @25℃

Power Characteristics

-10.0

+10.0

ppb

Vcc±5%

Load Characteristics

-10.0

+10.0

ppb

Load ± 5%

Short Term Frequency Stability

@t=1 s

5.0

E-12

The sample was placed in a sealed box at room temperature, free from EMI/EMC or other interference, and tested after being powered on for 2 hours. The test equipment was 53100A.

Phase Noise

@1Hz

——-

dBc/Hz

Placed in a sealed box at room temperature, free from EMI/EMC or other interference, and tested after 1 hour of power-on. Test equipment: E5052B.

@10Hz

-120

dBc/Hz

@100Hz

-140

dBc/Hz

@1KHz

-155

dBc/Hz

@10KHz

-158

dBc/Hz

@100KHz

-158

dBc/Hz

@1MHz

-158

dBc/Hz

Frequency Tuning

Frequency Adjustment Method

Voltage Regulation (Voltage Control)

—--

Voltage-Controlled Voltage Input (VC)

0～2.0～     4.0

VDC

Frequency Adjustment Range

VC=4.0V

0.5

ppm

Frequency deviation at @VC=2.0V

VC=2.0V

-0.1

0.1

ppm

@Frequency deviation of nominal frequency

VC=0V

-0.5

ppm

Frequency deviation at @VC=2.0V

Slope

Positive

——-

Linearity

10

%

Voltage-Controlled Input Impedance

100

KΩ

Noise of Voltage-Controlled Voltage(RMS)

30

uV

Reference Voltage Output (Vref)

3.8

4

4.2

VDC

Iout ≤ 1mA can be left floating

Ambient Temperature

Operating Temperature Range

-40

85

℃

Storage Temperature Range

-60

105

℃
