OCXO Oscillator 95MHz Sinewave

Supply Voltage: 5.0V
Temperature Stability: <±1ppb
Operating Temperature Range: -40~85℃
Low Phase Noise: 1KHz: ≤-160dBc/Hz

95MHz Ultra-High Stability OCXO (±1ppb)

Low Phase Noise | -40°C to +85°C | Precision Clock Reference

Product Overview

The XTALVCOCXO-3627-95M-5V-VF-SW is an industrial-grade, ultra-high stability Oven Controlled Crystal Oscillator. It delivers a 95MHz sine wave output with a world-class frequency stability of ≤±1ppb across a wide temperature range of -40°C to +85°C. Designed for high-performance RF environments, it features exceptional close-in phase noise (-100dBc/Hz @ 10Hz) and a noise floor of -170dBc/Hz, making it the premier choice for radar systems, microwave signal sources, and high-end test instrumentation.

Key Features：

Ultra-High Stability: ppb-level precision with ±0.5ppb daily aging and ±50ppb yearly performance.

Exceptional Close-in Phase Noise: Optimized for signal purity with -100dBc/Hz @ 10Hz offset.

Ultimate Short-Term Stability: Allan Deviation of 5ppt, providing a rock-solid timing reference.

Wide Temperature Range: Reliable operation from -40°C to +85°C.

Low Noise Floor: Clean spectral output reaching -170dBc/Hz floor.

Precision Frequency Control: 0-5V analog tuning range (>±0.25ppm) for precise system calibration.

Fast Warm-up: Reaches stability in under 5 minutes, ensuring rapid system readiness.

Applications：

Radar & Electronic Warfare: Low phase noise and high stability for superior target detection.

Microwave Signal Sources: High-purity reference for up/down converters and synthesizers.

Test & Measurement: Precision timebase for frequency counters and signal analyzers.

Satellite Communications: Reliable reference clock for SATCOM ground stations.

Technical data:

Feature	Parameters	Technical Indicators	Remarks
Output Characteristics	Nominal Frequency	95.00MHz
	Waveform	Sine wave	50Ω
	Signal Power	5dBm
	Harmonic Suppression	≤-45dBm
	Spurious Suppression	≤-80dBm
	Short-Term Frequency Stability	5ppt	Allen deviation, power-on time> 1h.
Frequency Stability	Ambient	≤±0.1ppm	-40～+85℃,fref=(fmax+fmin )/2
	Voltage	≤±2ppb	5.0V±5%
	Load	≤±2ppb	50Ω±5%
	Aging	≤±0.5ppb/day	After 30days
	Aging	≤±50ppb/year
Power Characteristics	Current	<1000mA	@turn on
	Steady Current	<500mA	@+25℃
	Voltage	5V	Vcc±5%
	Power-on Characteristics	≤±0.1ppm	Frequency deviation after 5 minutes of power on relative to 1 hour.
Voltage Control （Frequency Fine Tuning）	Tuning Voltage Range	0~5V	Center Voltage +2.0V
	Tuning Range	>±0.25ppm
	Slope	Positive
	Linearity	<10%
	Input Impedance	≥100KΩ
